ترانسفورماتور حس جریان
| عکس | شماره قطعه تولیدکننده | موجودی | تعداد | برگه مشخصات | سری | بسته بندی | وضعیت محصول | محدوده فرکانس | تایپ کنید | رتبه فعلی (آمپر) | اندوکتانس | ET (ولت-زمان) | نسبت چرخش - اولیه: ثانویه | نسبت فعلی | مقاومت DC (DCR) | رتبه بندی ها | نوع نصب | اندازه / ابعاد | ارتفاع - نشسته (حداکثر) | سبک خاتمه |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PCS040-EF1313KSCURRENT SENSE TRANSF 40A 13300UH |
0 |
|
برگه مشخصات |
PCS | Tape & Reel (TR) | Active | 1MHz | Invasive | 40 A | 13.3 mH | 317.5VµS | 1:125 | 125:1 | 1mOhm Primary, 1.85Ohm Secondary Max | - | Surface Mount | - | 0.413" (10.50mm) | Gull Wing |
|
|
PCS040-EF1302KSCURRENT SENSE TRANSF 40A 2120UH |
0 |
|
برگه مشخصات |
PCS | Tape & Reel (TR) | Active | 1MHz | Invasive | 40 A | 2.12 mH | 127VµS | 1:50 | 50:1 | 1mOhm Primary, 705mOhm Secondary Max | - | Surface Mount | - | 0.413" (10.50mm) | Gull Wing |
|
|
PCS040-EF13760SCURRENT SENSE TRANSF 40A 760UH |
0 |
|
برگه مشخصات |
PCS | Tape & Reel (TR) | Active | 1MHz | Invasive | 40 A | 760 µH | 76.2VµS | 1:30 | 30:1 | 1mOhm Primary, 265mOhm Secondary Max | - | Surface Mount | - | 0.413" (10.50mm) | Gull Wing |
|
PA3838NLCURR SENSE XFMR 1KA ROGOWSKI |
0 |
|
- |
- | - | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
750316793CURR SENSE XFMR 1:50 40A SMD |
0 |
|
برگه مشخصات |
- | Tape & Reel (TR) | Obsolete | 50kHz ~ 500kHz | Invasive | 40 A | 1.4 mH | - | 1:50 | - | 280mOhm | - | Surface Mount | 0.570" L x 0.795" W (14.48mm x 20.20mm) | 0.413" (10.50mm) | Gull Wing |
|
|
750316794CURR SENSE XFMR 1:100 40A SMD |
0 |
|
برگه مشخصات |
- | Tape & Reel (TR) | Obsolete | 50kHz ~ 500kHz | Invasive | 40 A | 5.6 mH | - | 1:100 | - | 280mOhm | - | Surface Mount | 0.570" L x 0.795" W (14.48mm x 20.20mm) | 0.413" (10.50mm) | Gull Wing |
|
|
750316795CURR SENSE XFMR 1:150 40A SMD |
0 |
|
برگه مشخصات |
- | Tape & Reel (TR) | Obsolete | 50kHz ~ 500kHz | Invasive | 40 A | 12.6 mH | - | 1:150 | - | 280mOhm | - | Surface Mount | 0.570" L x 0.795" W (14.48mm x 20.20mm) | 0.413" (10.50mm) | Gull Wing |
|
AS-115CURR SENSE XFMR 1:750CT 30A T/H |
0 |
|
برگه مشخصات |
AS | Tray | Active | 20kHz ~ 200kHz | Non-Invasive (Solid Core) | - | 1.68 mH | 3750VµS | 1:750CT | - | 21.5Ohm Max | - | Through Hole | 0.677" L x 0.375" W (17.20mm x 9.53mm) | 0.803" (20.40mm) | PC Pin |
|
T60404E4626X0024626X002 |
0 |
|
- |
- | Box | Active | - | Non-Invasive (Solid Core) | 100 A | 102 H | - | 2500:1 | 2500:1 | 41.7Ohm | - | Free Hanging (In-Line) | 1.339" L x 0.591" W (34.00mm x 15.00mm) | 1.378" (35.00mm) | Wire Leads |
|
|
T60404S4658X0514658X051 |
0 |
|
- |
- | Box | Active | - | Non-Invasive (Solid Core) | 100 A | 63 H | - | 1:2000 | 2000:1 | 51Ohm | - | Through Hole | 1.063" L x 0.492" W (27.00mm x 12.50mm) | 1.161" (29.50mm) | PC Pin |
|
|
AS-401CURR SENSE XFMR 2A 1:100 VRT |
0 |
|
برگه مشخصات |
AS | Bulk | Active | - | - | - | - | - | - | - | - | - | - | 0.906" L x 0.610" W (23.00mm x 15.50mm) | 0.984" (25.00mm) | - |
|
ECST1V0805-1030-RCURR SENSE XFMR 30:1 10A SMD |
0 |
|
برگه مشخصات |
ECST | Tape & Reel (TR) | Active | 50kHz ~ 1MHz | Invasive | 10 A | 180 µH | - | 30:1 | - | 700mOhm Primary, 870mOhm Secondary Max | - | Surface Mount | 0.330" L x 0.315" W (8.38mm x 8.00mm) | 0.217" (5.50mm) | Gull Wing |
|
AX-1500CURR SENSE XFMR 15A T/H |
0 |
|
برگه مشخصات |
AX | Tray | Active | 50Hz ~ 60Hz | Non-Invasive (Solid Core) | 15 A | - | - | - | 1500:1 | - | - | Through Hole | 0.677" L x 0.375" W (17.20mm x 9.53mm) | 0.803" (20.40mm) | PC Pin |
|
|
T60404E4624X1314624X131 |
0 |
|
- |
- | Box | Active | 50Hz | Non-Invasive (Solid Core) | 60 A | 3.8 H | - | 2500:1 | 2500:1 | 71.5Ohm | - | Free Hanging (In-Line) | 1.287" L x 0.642" W (32.70mm x 16.30mm) | 1.366" (34.70mm) | Wire Leads |
|
|
T60404E4624X5314624X531 |
0 |
|
- |
- | Box | Active | - | Non-Invasive (Solid Core) | 60 A | 3.8 H | - | 1:2500 | 2500:1 | - | - | Through Hole | 1.260" L x 0.618" W (32.00mm x 15.70mm) | 1.280" (32.50mm) | PC Pin |
|
AP-2000CURR SENSE XFMR 15A T/H |
0 |
|
برگه مشخصات |
AP | Tray | Active | - | Non-Invasive (Solid Core) | 15 A | - | - | - | 2000:1 | 235Ohm Max | - | Through Hole | 0.677" L x 0.375" W (17.20mm x 9.53mm) | 0.803" (20.40mm) | PC Pin |
|
|
T60404E4626X5314626X531 |
0 |
|
- |
- | Box | Active | - | Non-Invasive (Solid Core) | 100 A | 3.1 H | - | 1:2500 | 2500:1 | 50Ohm | - | Through Hole | 1.469" L x 0.665" W (37.30mm x 16.90mm) | 1.457" (37.00mm) | PC Pin |
|
|
ECST1V0805-1060-RCURR SENSE XFMR 60:1 10A SMD |
0 |
|
برگه مشخصات |
ECST | Tape & Reel (TR) | Active | 50kHz ~ 1MHz | Invasive | 10 A | 730 µH | - | 60:1 | - | 700mOhm Primary, 2.3Ohm Secondary Max | - | Surface Mount | 0.330" L x 0.315" W (8.38mm x 8.00mm) | 0.217" (5.50mm) | Gull Wing |
|
|
ECST1V0805-1070-RCURR SENSE XFMR 70:1 10A SMD |
0 |
|
برگه مشخصات |
ECST | Tape & Reel (TR) | Active | 50kHz ~ 1MHz | Invasive | 10 A | 980 µH | - | 70:1 | - | 700mOhm Primary, 4.75Ohm Secondary Max | - | Surface Mount | 0.330" L x 0.315" W (8.38mm x 8.00mm) | 0.217" (5.50mm) | Gull Wing |
|
|
ECST1V0805-1040-RCURR SENSE XFMR 40:1 10A SMD |
0 |
|
برگه مشخصات |
ECST | Tape & Reel (TR) | Active | 50kHz ~ 1MHz | Invasive | 10 A | 320 µH | - | 40:1 | - | 700mOhm Primary, 1.14Ohm Secondary Max | - | Surface Mount | 0.330" L x 0.315" W (8.38mm x 8.00mm) | 0.217" (5.50mm) | Gull Wing |
