سوئیچ های آنالوگ، مولتی پلکسر، دی مولتی پلکسر
| عکس | شماره قطعه تولیدکننده | موجودی | تعداد | برگه مشخصات | سری | بسته بندی | وضعیت محصول | مدار سوئیچ | مدار مالتی پلکسر/دی مولتی پلکسر | تعداد مدارها | مقاومت در ایالت (حداکثر) | تطبیق کانال به کانال (ΔRon) | ولتاژ - منبع تغذیه، تک (V+) | ولتاژ - منبع تغذیه، دوگانه (V±) | زمان سوئیچ (تن، خاموش) (حداکثر) | - پهنای باند 3db | تزریق شارژ | ظرفیت کانال (CS(خاموش)، CD(خاموش)) | جریان - نشتی (IS(خاموش)) (حداکثر) | متقاطع | دمای عملیاتی | درجه | صلاحیت | نوع نصب | بسته دستگاه تامین کننده |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PS383ESEIC SWITCH SPDT X 2 30OHM 16SOIC |
0 |
|
برگه مشخصات |
- | Tube | Obsolete | SPDT | 2:1 | 2 | 30Ohm | 200mOhm | 3V ~ 15V | ±3V ~ 8V | 130ns, 75ns | - | 2pC | 12pF, 12pF | 100pA | -90dB @ 1MHz | -40°C ~ 85°C (TA) | - | - | Surface Mount | 16-SOIC |
|
|
PS398CSEIC MUX 8:1 100OHM 16SOIC |
0 |
|
برگه مشخصات |
- | Tube | Obsolete | - | 8:1 | 1 | 100Ohm | 6Ohm (Max) | 3V ~ 15V | ±3V ~ 8V | 150ns, 150ns | - | 2.8pC | 3.6pF, 31pF | 50nA | -92dB @ 100kHz | - | - | - | Surface Mount | 16-SOIC |
|
ADG904BCPZ-REELIC SWITCH SP4T X 1 20LFCSP |
0 |
|
برگه مشخصات |
- | Tape & Reel (TR) | Active | SP4T | 4:1 | 1 | - | - | 1.65V ~ 2.75V | - | 10ns, 16ns | 2.5GHz | - | 2pF | 1µA | -58dB @ 100MHz | -40°C ~ 85°C (TA) | - | - | Surface Mount | 20-LFCSP (4x4) |
|
MAX4616CUD+TIC SW SPST-NO/NCX4 10OHM 14TSSOP |
0 |
|
برگه مشخصات |
- | Tape & Reel (TR) | Active | SPST - NO/NC | 1:1 | 4 | 10Ohm | 200mOhm | 2V ~ 5.5V | - | 12ns, 10ns | 70MHz | 6.5pC | 5pF, 5pF | 1nA | -96dB @ 100kHz | 0°C ~ 70°C (TA) | - | - | Surface Mount | 14-TSSOP |
|
MAX4614CSD+TIC SWITCH SPST-NOX4 10OHM 14SOIC |
0 |
|
برگه مشخصات |
- | Tape & Reel (TR) | Active | SPST - NO | 1:1 | 4 | 10Ohm | 200mOhm | 2V ~ 5.5V | - | 12ns, 10ns | 70MHz | 6.5pC | 5pF, 5pF | 1nA | -96dB @ 100kHz | 0°C ~ 70°C (TA) | - | - | Surface Mount | 14-SOIC |
|
TMUX7348FPWR60V FAULT-PROTECTED, 8:1 MULTIPL |
0 |
|
برگه مشخصات |
- | Tape & Reel (TR) | Active | SP8T - Open | 8:1 | 1 | 250Ohm | 2.5Ohm | 8V ~ 44V | ±5V ~ 22V | 300ns, 400ns | 150MHz | -17pC | 3.5pF, 28pF | 1nA | -95dB @ 1MHz | -40°C ~ 125°C (TA) | - | - | Surface Mount | 20-TSSOP |
|
MAX362EPEIC SWITCH SPST-NOX4 85OHM 16DIP |
0 |
|
برگه مشخصات |
- | Tube | Obsolete | SPST - NO | 1:1 | 4 | 85Ohm | 2Ohm (Max) | 10V ~ 30V | ±4.5V ~ 20V | 250ns, 120ns | - | 5pC | 4pF, 4pF | 500pA | -100dB @ 1MHz | -40°C ~ 85°C (TA) | - | - | Through Hole | 16-PDIP |
|
MAX4524CUB+TIC SWITCH SP4T X 1 150OHM 10UMAX |
0 |
|
برگه مشخصات |
- | Tape & Reel (TR) | Active | SP4T | 4:1 | 1 | 150Ohm | 2Ohm | 2V ~ 12V | - | 150ns, 120ns | - | 0.8pC | 4pF, 14pF | 1nA | - | 0°C ~ 70°C (TA) | - | - | Surface Mount | 10-uMAX/uSOP |
|
|
MAX4525CUB+TIC SWITCH DPDT X 1 150OHM 10UMAX |
0 |
|
برگه مشخصات |
- | Tape & Reel (TR) | Active | DPDT | 2:1 | 1 | 150Ohm | 2Ohm | 2V ~ 12V | - | 150ns, 120ns | - | 0.8pC | 4pF, 6pF | 1nA | -74dB @ 1MHz | 0°C ~ 70°C (TA) | - | - | Surface Mount | 10-uMAX/uSOP |
|
MAX4613CUE+TIC SW SPST-NO/NCX4 70OHM 16TSSOP |
0 |
|
برگه مشخصات |
- | Tape & Reel (TR) | Active | SPST - NO/NC | 1:1 | 4 | 70Ohm | 4Ohm (Max) | 4.5V ~ 40V | ±4.5V ~ 20V | 250ns, 120ns | - | 5pC | 4pF, 4pF | 500pA | -100dB @ 1MHz | 0°C ~ 70°C (TA) | - | - | Surface Mount | 16-TSSOP |
|
|
MAX4613ESE+TIC SW SPST-NO/NCX4 70OHM 16SOIC |
0 |
|
برگه مشخصات |
- | Tape & Reel (TR) | Active | SPST - NO/NC | 1:1 | 4 | 70Ohm | 4Ohm (Max) | 4.5V ~ 40V | ±4.5V ~ 20V | 250ns, 120ns | - | 5pC | 4pF, 4pF | 500pA | -100dB @ 1MHz | -40°C ~ 85°C (TA) | - | - | Surface Mount | 16-SOIC |
|
DG9408DN-T1-E4IC MUX 8:1 7OHM 16QFN |
0 |
|
برگه مشخصات |
- | Tape & Reel (TR) | Obsolete | - | 8:1 | 1 | 7Ohm | 3.6Ohm (Max) | 2.7V ~ 12V | ±3V ~ 6V | 70ns, 44ns | - | 29pC | 21pF, 211pF | 2nA | -85dB @ 100kHz | -40°C ~ 85°C (TA) | - | - | Surface Mount | 16-QFN (4x4) |
|
|
DG9409DN-T1-E4IC SWITCH SP4T X 2 7OHM 16QFN |
0 |
|
برگه مشخصات |
- | Tape & Reel (TR) | Obsolete | SP4T | 4:1 | 2 | 7Ohm | 3.6Ohm (Max) | 2.7V ~ 12V | ±3V ~ 6V | 70ns, 44ns | - | 29pC | 23pF, 112pF | 2nA | -85dB @ 100kHz | -40°C ~ 85°C (TA) | - | - | Surface Mount | 16-QFN (4x4) |
|
MAX4657EUA+TIC SWITCH SPST-NCX1 10OHM 8UMAX |
0 |
|
برگه مشخصات |
- | Tape & Reel (TR) | Active | SPST - NC | 1:1 | 1 | 10Ohm | - | 9V ~ 40V | ±4.5V ~ 20V | 200ns, 100ns | 210MHz | 23pC | 25pF, 25pF | 1nA | - | -40°C ~ 85°C (TA) | - | - | Surface Mount | 8-uMAX/uSOP |
|
|
MAX4658EUA+TIC SWITCH SPST-NOX1 10OHM 8UMAX |
0 |
|
برگه مشخصات |
- | Tape & Reel (TR) | Active | SPST - NO | 1:1 | 1 | 10Ohm | - | 9V ~ 40V | ±4.5V ~ 20V | 200ns, 100ns | 210MHz | 23pC | 25pF, 25pF | 1nA | - | -40°C ~ 85°C (TA) | - | - | Surface Mount | 8-uMAX/uSOP |
|
AS1742H-TIC SW SPST-NCX2 800MOHM SOT23-8 |
0 |
|
برگه مشخصات |
- | Tape & Reel (TR) | Active | SPST - NC | 1:1 | 2 | 800mOhm | 20mOhm | 1.6V ~ 3.6V | - | 22ns, 14ns | 130MHz | 5pC | 35pF, 35pF | 1nA | -100dB @ 1MHz | -40°C ~ 85°C (TA) | - | - | Surface Mount | SOT-23-8 |
|
|
MAX351CPEIC SWITCH SPST-NCX4 35OHM 16DIP |
0 |
|
برگه مشخصات |
- | Tube | Obsolete | SPST - NC | 1:1 | 4 | 35Ohm | 2Ohm (Max) | 10V ~ 30V | ±4.5V ~ 20V | 175ns, 145ns | - | 5pC | 9pF, 9pF | 250pA | -85dB @ 1MHz | 0°C ~ 70°C (TA) | - | - | Through Hole | 16-PDIP |
|
|
MAX352CPEIC SWITCH SPST-NOX4 35OHM 16DIP |
0 |
|
برگه مشخصات |
- | Tube | Obsolete | SPST - NO | 1:1 | 4 | 35Ohm | 2Ohm (Max) | 10V ~ 30V | ±4.5V ~ 20V | 175ns, 145ns | - | 5pC | 9pF, 9pF | 250pA | -85dB @ 1MHz | 0°C ~ 70°C (TA) | - | - | Through Hole | 16-PDIP |
|
|
MAX353CPEIC SW SPST-NO/NCX4 35OHM 16DIP |
0 |
|
برگه مشخصات |
- | Tube | Obsolete | SPST - NO/NC | 1:1 | 4 | 35Ohm | 2Ohm (Max) | 10V ~ 30V | ±4.5V ~ 20V | 175ns, 145ns | - | 5pC | 9pF, 9pF | 250pA | -85dB @ 1MHz | 0°C ~ 70°C (TA) | - | - | Through Hole | 16-PDIP |
|
MAX4657ESA+TIC SWITCH SPST-NCX1 10OHM 8SOIC |
0 |
|
برگه مشخصات |
- | Tape & Reel (TR) | Active | SPST - NC | 1:1 | 1 | 10Ohm | - | 9V ~ 40V | ±4.5V ~ 20V | 200ns, 100ns | 210MHz | 23pC | 25pF, 25pF | 1nA | - | -40°C ~ 85°C (TA) | - | - | Surface Mount | 8-SOIC |
