رله های برق، بیش از 2 آمپر
| عکس | شماره قطعه تولیدکننده | موجودی | تعداد | برگه مشخصات | سری | بسته بندی | وضعیت محصول | نوع نصب | ولتاژ سیم پیچ | فرم تماس | رتبه بندی تماس (جاری) | ولتاژ سوئیچینگ | بار - حداکثر سوئیچینگ | جریان سیم پیچ | نوع کویل | ویژگی ها | سبک خاتمه | رتبه بندی مهر و موم | عایق کویل | ولتاژ باید کار کند | ولتاژ باید آزاد شود | زمان عملیات | زمان انتشار | دمای عملیاتی | مواد تماس | آژانس تایید | نوع رله | درجه | صلاحیت |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PT270506RELAY GEN PURPOSE DPDT 12A 6V |
0 |
|
برگه مشخصات |
PT, SCHRACK | Bulk | Active | Socketable | 6VAC | DPDT (2 Form C) | 12 A | 400VAC - Max | 4800VA | 545.5 mA | Non Latching | Mechanical Indicator, Test Button | Plug In, Quick Connect - 0.110" (2.8mm) | - | Class F | 4.8 VAC | 1.8 VAC | - | - | -40°C ~ 70°C | Silver Nickel (AgNi) | cURus, VDE | General Purpose | - | - |
|
ADJ11012RELAY GEN PURPOSE SPDT 16A 12V |
0 |
|
برگه مشخصات |
ADJ | Tube | Active | Through Hole | 12VDC | SPDT (1 Form C) | 16 A | 250VAC - Max | 4000VA | 12.5 mA | Latching, Single Coil | - | PC Pin | Sealed - Flux Protection | - | 8.4 VDC | - | 20 ms | 20 ms | -40°C ~ 70°C | Silver Tin Oxide (AgSnO) | CQC, cURus, VDE | General Purpose | - | - |
|
|
ADJ21005RELAY GEN PURPOSE SPST 16A 5V |
0 |
|
برگه مشخصات |
ADJ | Tube | Active | Through Hole | 5VDC | SPST-NO (1 Form A) | 16 A | 250VAC - Max | 4000VA | 30 mA | Latching, Single Coil | - | PC Pin | Sealed - Flux Protection | - | 3.5 VDC | - | 20 ms | 20 ms | -40°C ~ 70°C | Silver Tin Oxide (AgSnO) | CQC, cURus, VDE | General Purpose | - | - |
|
|
ADJ21024RELAY GEN PURPOSE SPST 16A 24V |
0 |
|
برگه مشخصات |
ADJ | Tube | Active | Through Hole | 24VDC | SPST-NO (1 Form A) | 16 A | 250VAC - Max | 4000VA | 6.3 mA | Latching, Single Coil | - | PC Pin | Sealed - Flux Protection | - | 16.8 VDC | - | 20 ms | 20 ms | -40°C ~ 70°C | Silver Tin Oxide (AgSnO) | CQC, cURus, VDE | General Purpose | - | - |
|
ADJ22012RELAY GEN PURPOSE SPST 16A 12V |
0 |
|
برگه مشخصات |
ADJ | Tube | Active | Through Hole | 12VDC | SPST-NO (1 Form A) | 16 A | 250VAC - Max | 4000VA | 12.5 mA | Latching, Single Coil | - | PC Pin | Sealed - Fully | - | 8.4 VDC | - | 20 ms | 20 ms | -40°C ~ 70°C | Silver Tin Oxide (AgSnO) | CQC, cURus, VDE | General Purpose | - | - |
|
DK1A1B-6VRELAY GEN PURPOSE DPST 8A 6V |
0 |
|
برگه مشخصات |
DK | Box | Active | Through Hole | 6VDC | DPST-NO/NC (1 Form A, 1 Form B) | 8 A | 250VAC, 125VDC - Max | 2000VA, 1000W | 33.3 mA | Non Latching | - | PC Pin | Sealed - Fully | - | 4.2 VDC | 0.6 VDC | 10 ms | 8 ms | -40°C ~ 65°C | Silver Nickel (AgNi) | CSA, TUV, UR, VDE | General Purpose | - | - |
|
|
DK1A1B-9VRELAY GEN PURPOSE DPST 8A 9V |
0 |
|
برگه مشخصات |
DK | Box | Active | Through Hole | 9VDC | DPST-NO/NC (1 Form A, 1 Form B) | 8 A | 250VAC, 125VDC - Max | 2000VA, 1000W | 22.2 mA | Non Latching | - | PC Pin | Sealed - Fully | - | 6.3 VDC | 0.9 VDC | 10 ms | 8 ms | -40°C ~ 65°C | Silver Nickel (AgNi) | CSA, TUV, UR, VDE | General Purpose | - | - |
|
PC740-2C-C1-12DRELAY GEN PURPOSE DPDT 40A 12V |
0 |
|
برگه مشخصات |
PC740 | Bag | Active | Chassis Mount | 12VDC | DPDT (2 Form C) | 40 A | 250VAC, 28VDC - Max | 10000VA, 1120W | 206.9 mA | Non Latching | - | Quick Connect - 0.250" (6.3mm) | - | Class B | 9.6 VDC | 1 VDC | 25 ms | 15 ms | -55°C ~ 70°C | Silver Cadmium Oxide (AgCdO) | CUL, cURus, UL | General Purpose | - | - |
|
RP421006RELAY GEN PURPOSE DPDT 8A 6V |
0 |
|
برگه مشخصات |
RP II/2, SCHRACK | Tube | Active | Through Hole | 6VDC | DPDT (2 Form C) | 8 A | 400VAC - Max | 3200VA | 88.2 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | - | 4.2 VDC | 0.6 VDC | 9 ms | 3 ms | -40°C ~ 70°C | Silver Nickel (AgNi) | cURus, VDE | General Purpose | - | - |
|
RJ1V-AH-A24RELAY PCB SPST-NO 16A 24VAC |
0 |
|
- |
RJ | Bulk | Active | Through Hole | 24VAC | SPST-NO (1 Form A) | 16 A | 250VAC, 125VDC - Nom | - | 37.5 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | - | 19.2 VAC | 7.2 VAC | 15 ms | 10 ms | -40°C ~ 70°C | Silver Nickel (AgNi) | CE, CSA, cURus, VDE | General Purpose | - | - |
|
|
RJ1V-CH-A24RELAY PCB SPDT 16A 24VAC |
0 |
|
- |
RJ | Bulk | Active | Through Hole | 24VAC | SPDT (1 Form C) | 16 A | 250VAC, 125VDC - Nom | - | 37.5 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | - | 19.2 VAC | 7.2 VAC | 15 ms | 10 ms | -40°C ~ 70°C | Silver Nickel (AgNi) | CE, CSA, cURus, VDE | General Purpose | - | - |
|
|
J1671AF220VDCQRELAY GEN PURPOSE SPST |
0 |
|
برگه مشخصات |
J167 | Tray | Active | Chassis Mount | 220VDC | SPST-NO (1 Form A) | 30 A | 277VAC, 30VDC - Max | 6600VA | 8.6 mA | Non Latching | - | Quick Connect - 0.250" (6.3mm) | - | Class F | 154 VDC | 22 VDC | 30 ms | 30 ms | -40°C ~ 85°C | Silver Tin Oxide Indium Oxide (AgSnOInO) | cURus, TUV | General Purpose | - | - |
|
|
J1671AF6VACQRELAY GEN PURPOSE SPST |
0 |
|
برگه مشخصات |
J167 | Tray | Active | Chassis Mount | 6VAC | SPST-NO (1 Form A) | 30 A | 277VAC, 30VDC - Max | 6600VA | 428.6 mA | Non Latching | - | Quick Connect - 0.250" (6.3mm) | - | Class F | 4.2 VAC | 0.6 VAC | 30 ms | 30 ms | -40°C ~ 85°C | Silver Tin Oxide Indium Oxide (AgSnOInO) | cURus, TUV | General Purpose | - | - |
|
|
MY2NAC48/50(S)RELAY GEN PURPOSE DPDT 5A 50V |
0 |
|
- |
MY | Bulk | Last Time Buy | Socketable | 50VAC | DPDT (2 Form C) | 5 A | 250VAC, 125VDC - Max | 1250VA, 625W | - | Non Latching | Lighted Indicator | Plug In | - | - | - | - | 20 ms | 20 ms | -55°C ~ 60°C | Silver (Ag) | CE, CSA, UR, VDE | General Purpose | - | - |
|
|
AZEV200-2AE-24DRELAY EV CHARGING DPST 40A 24V |
0 |
|
برگه مشخصات |
AZEV200 | Tube | Active | Through Hole | 24VDC | DPST-NO (2 Form A) | 40 A | 480VAC - Max | 19200VA | 108 mA | Non Latching | - | PC Pin | - | Class F | 18 VDC | 1.2 VDC | 30 ms | 10 ms | -40°C ~ 95°C | Silver Tin Oxide (AgSnO) | CQC, cURus, TUV | EV Charging | - | - |
|
G2RK-1 DC6 BY OMIRELAY GEN PURPOSE SPDT 5A 6V |
0 |
|
برگه مشخصات |
G2R | Tray | Active | Through Hole | 6VDC | SPDT (1 Form C) | 5 A | 380VAC, 125VDC - Max | 1900VA, 625W | 138 mA | Latching, Dual Coil | - | PC Pin | Sealed - Flux Protection | - | 4.2 VDC | - | 20 ms | 20 ms | -40°C ~ 70°C | Silver Alloy | CSA, TUV, UR, VDE | General Purpose | - | - |
|
|
AZSR250-1AE-12DRELAY EV CHG SOLAR SPST 55A 12V |
0 |
|
- |
AZSR250 | Tube | Active | Through Hole | 12VDC | SPST-NO (1 Form A) | 55 A | 440VAC, 150VDC - Max | 13850VA 1500W | 40 mA | Non Latching | - | PC Pin | - | Class F | 9 VDC | 0.6 VDC | 40 ms | 5 ms | -40°C ~ 85°C | Silver Tin Oxide (AgSnO) | cURus, VDE | EV Charging, Solar | - | - |
|
|
5-1393304-7RELAY GEN PURPOSE DPST 25A 12V |
0 |
|
برگه مشخصات |
F4 | Bulk | Active | Through Hole | 12VDC | DPST-NO (2 Form A) | 25 A | 14VDC - Nom | - | 133.3 mA | Non Latching | - | PC Pin | - | - | 7.2 VDC | 1.6 VDC | 7 ms | 2 ms | -40°C ~ 125°C | Silver Alloy | - | General Purpose | - | - |
|
|
55.12.8.120.0000RELAY GEN PURPOSE DPDT 10A 120V |
0 |
|
برگه مشخصات |
55 | Bulk | Active | Through Hole | 120VAC | DPDT (2 Form C) | 10 A | 400VAC - Max | 4000VA | 12 mA | Non Latching | - | PC Pin | - | - | 96 VAC | 24 VAC | 10 ms | 5 ms | -40°C ~ 85°C | Silver Nickel (AgNi) | CCC, CSA, cURus, EAC, ENEC, RINA, VDE | General Purpose | - | - |
|
|
ADJ11005RELAY GEN PURPOSE SPDT 16A 5V |
0 |
|
برگه مشخصات |
ADJ | Tube | Active | Through Hole | 5VDC | SPDT (1 Form C) | 16 A | 250VAC - Max | 4000VA | 30 mA | Latching, Single Coil | - | PC Pin | Sealed - Flux Protection | - | 3.5 VDC | - | 20 ms | 20 ms | -40°C ~ 70°C | Silver Tin Oxide (AgSnO) | CQC, cURus, VDE | General Purpose | - | - |
