رله های برق، بیش از 2 آمپر
| عکس | شماره قطعه تولیدکننده | موجودی | تعداد | برگه مشخصات | سری | بسته بندی | وضعیت محصول | نوع نصب | ولتاژ سیم پیچ | فرم تماس | رتبه بندی تماس (جاری) | ولتاژ سوئیچینگ | بار - حداکثر سوئیچینگ | جریان سیم پیچ | نوع کویل | ویژگی ها | سبک خاتمه | رتبه بندی مهر و موم | عایق کویل | ولتاژ باید کار کند | ولتاژ باید آزاد شود | زمان عملیات | زمان انتشار | دمای عملیاتی | مواد تماس | آژانس تایید | نوع رله | درجه | صلاحیت |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
RH1B-UCDC48VRELAY PLUG-IN SPDT 10A 48VDC |
0 |
|
برگه مشخصات |
RH | Bulk | Active | Socketable | 48VDC | SPDT (1 Form C) | 10 A | 240VAC, 30VDC - Max | 2400VA, 300W | 18 mA | Non Latching | Test Button | Plug In, Quick Connect - 0.187" (4.7mm) | - | - | 38.4 VDC | 4.8 VDC | 20 ms | 20 ms | -25°C ~ 70°C | Silver Cadmium Oxide (AgCdO) | CE, CSA, cURus, TUV | General Purpose | - | - |
|
|
RH1V2-UCDC24VRELAY PCB SPDT 10A 24VDC |
0 |
|
برگه مشخصات |
RH | Bulk | Active | Through Hole | 24VDC | SPDT (1 Form C) | 10 A | 240VAC, 30VDC - Max | 2400VA, 300W | 32 mA | Non Latching | Test Button | PC Pin | - | - | 19.2 VDC | 2.4 VDC | 20 ms | 20 ms | -25°C ~ 70°C | Silver Cadmium Oxide (AgCdO) | CE, CSA, cURus, TUV | General Purpose | - | - |
|
S4EB-L2-48VRELAY GEN PURPOSE 4PST 4A 48V |
0 |
|
برگه مشخصات |
S | Box | Active | Through Hole | 48VDC | 4PST-NO (4 Form A) | 4 A | 250VAC, 48VDC - Max | 1000VA, 192W | 7.4 mA | Latching, Dual Coil | - | PC Pin | Sealed - Fully | - | 33.6 VDC | - | 15 ms | 15 ms | -55°C ~ 65°C | Silver Alloy, Cadmium Free | CSA, UR | General Purpose | - | - |
|
AHES4195RELAY GEN PURPOSE 3PST 35A 9V |
0 |
|
برگه مشخصات |
HE-S | Tray | Active | Through Hole | 9VDC | 3PST-2NO/1NC (2 Form A, 1 Form B) | 35 A | 277VAC - Nom | - | 209 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | Class F | 6.3 VDC | 0.45 VDC | 30 ms | 10 ms | -40°C ~ 55°C | Silver Tin Oxide (AgSnO) | CQC, cURus, VDE | General Purpose | - | - |
|
2909885RELAY GEN PURPOSE SPST 6A 24V |
5 |
|
برگه مشخصات |
RIF | Bulk | Obsolete | DIN Rail | 24VDC | SPST-NO (1 Form A) | 6 A | 250VAC, 250VDC - Max | - | 18 mA | Non Latching | Diode, Lighted Indicator, Socket Included | Screw Terminal | - | - | - | - | 8 ms | 10 ms | -40°C ~ 70°C | Silver Tin Oxide (AgSnO) | CSA | General Purpose | - | - |
|
|
3-1415046-1RELAY GEN PURP |
0 |
|
برگه مشخصات |
PT, SCHRACK | Bulk | Active | Through Hole | 12VDC | 4PDT (4 Form C) | 6 A | 240VAC - Max | 1440VA | 62.5 mA | Non Latching | Test Button | PC Pin | - | Class F | 9 VDC | 1.2 VDC | 15 ms | 10 ms | -40°C ~ 70°C | Silver Nickel (AgNi) | cURus, VDE | General Purpose | - | - |
|
MT326230RELAY GEN PURPOSE 3PDT 10A 230V |
0 |
|
برگه مشخصات |
MT, SCHRACK | Bulk | Obsolete | Socketable | 230VAC | 3PDT (3 Form C) | 10 A | 400VAC - Max | 2500VA | 27.7 mA | Non Latching | Test Button | Plug In, 11 Pin (Octal) | - | Class B | 184 VAC | 92 VAC | 15 ms | 10 ms | -40°C ~ 50°C | Silver Nickel (AgNi) | cURus, VDE | General Purpose | - | - |
|
|
156-14U200RELAY GEN PURP |
0 |
|
- |
156, CII | Bulk | Active | Socketable | 240VAC | 4PDT (4 Form C) | 5 A | 240VAC - Nom | - | 70.6 mA | Non Latching | - | Solder Lug | - | - | 204 VAC | 72 VAC | 25 ms | 25 ms | -25°C ~ 55°C | Silver Cadmium Oxide (AgCdO) | CSA, TUV, UL | General Purpose | - | - |
|
|
RU2V-NF-A220RELAY DPDT 10A PCB 220-240VAC |
0 |
|
- |
RU | Bulk | Active | Through Hole | 220VAC | DPDT (2 Form C) | 10 A | 250VAC, 30VDC - Max | 2500VA, 300W | 3.6 mA | Non Latching | Lighted Indicator, Mechanical Indicator | PC Pin | - | - | 176 VAC | 66 VAC | 20 ms | 20 ms | -55°C ~ 70°C | Silver Alloy | CE, CSA, cURus, TUV | General Purpose | - | - |
|
|
RU2S-C-A220RELAY PLUG-IN DPDT 10A 240VAC |
0 |
|
- |
RU | Bulk | Active | Socketable | 220VAC | DPDT (2 Form C) | 10 A | 250VAC, 30VDC - Max | 2500VA, 300W | 3.6 mA | Non Latching | Lighted Indicator, Mechanical Indicator | Plug In, 8 Pin | - | - | 176 VAC | 66 VAC | 20 ms | 20 ms | -55°C ~ 60°C | Silver Alloy | CE, CSA, cURus, TUV | General Purpose | - | - |
|
T92P7D42-24-01RELAY GEN PURPOSE DPST 30A 24V |
0 |
|
برگه مشخصات |
T92 | Bulk | Active | Chassis Mount | 24VDC | DPST-NO (2 Form A) | 30 A | 600VAC - Max | 18000VA | 68.6 mA | Non Latching | - | Quick Connect - 0.187"/0.250" | - | Class F | 18 VDC | 2.4 VDC | 25 ms | 25 ms | -55°C ~ 85°C | Silver Cadmium Oxide (AgCdO) | UR | General Purpose | - | - |
|
|
62.22.9.024.0300PCB POWER RELAY, DPST-NO 15A , 2 |
0 |
|
برگه مشخصات |
62 | Bulk | Obsolete | Through Hole | 24VDC | DPST-NO (2 Form A) | 16 A | 400VAC - Max | 6400VA | 125 mA | Non Latching | - | PC Pin | - | - | 20.4 VDC | 4.8 VDC | 15 ms | 3 ms | -40°C ~ 50°C | Silver Cadmium Oxide (AgCdO) | CCC, CSA, cURus, EAC, ENEC, RINA, VDE | General Purpose | - | - |
|
RM332024RELAY GEN PURPOSE 3PDT 10A 24V |
0 |
|
برگه مشخصات |
RM, SCHRACK | Bulk | Obsolete | Socketable | 24VDC | 3PDT (3 Form C) | 10 A | 440VAC - Max | 4000VA | 50 mA | Non Latching | Mechanical Indicator, Test Button | Plug In, Quick Connect - 0.187" (4.7mm) | - | - | 18 VDC | 2.4 VDC | 15 ms | 10 ms | -45°C ~ 60°C | Silver Cadmium Oxide (AgCdO) | cURus, VDE | General Purpose | - | - |
|
|
G4D-212P-US-TV2-DC24RELAY GEN PURPOSE DPDT 5A 24V |
0 |
|
برگه مشخصات |
G4D | Bulk | Obsolete | Through Hole | 24VDC | DPDT (2 Form C) | 5 A | 250VAC - Max | 1250VA | - | - | - | PC Pin | - | - | - | - | - | - | - | - | - | General Purpose | - | - |
|
|
781XAXRM4L-24A781R PLUG-IN RELAY, SPDT, 15A, 2 |
0 |
|
- |
Legacy | Box | Active | Socketable | 24VAC | SPDT (1 Form C) | 15 A | 300VAC, 28VDC - Max | 4500VA, 420W | 135.6 mA | Non Latching | Test Button | Plug In | - | - | 19.2 VAC | 3.6 VAC | 20 ms | 20 ms | -40°C ~ 55°C | Silver (Ag), Gold (Au) | - | General Purpose | - | - |
|
|
55.32.9.125.0080IND. PLUG-IN RELAY, DPDT 10A, 12 |
2 |
|
برگه مشخصات |
55 | Bulk | Active | Socketable | 125VDC | DPDT (2 Form C) | 10 A | 400VAC - Max | 4000VA | 7.2 mA | Non Latching | Diode, Lighted Indicator | Plug In | - | - | 100 VDC | 25 VDC | 10 ms | 5 ms | -40°C ~ 85°C | Silver Nickel (AgNi) | CCC, CE, CSA, cURus, EAC, ENEC, RINA, UKCA, VDE | General Purpose | - | - |
|
|
56.32.9.125.0000IND. PLUG-IN RELAY, DPDT 12A, 12 |
0 |
|
برگه مشخصات |
56 | Bulk | Active | Socketable | 125VDC | DPDT (2 Form C) | 12 A | 400VAC - Max | 4800VA | 7.2 mA | Non Latching | - | Plug In, Quick Connect - 0.187" (4.7mm) | - | - | 100 VDC | 25 VDC | 9 ms | 6 ms | -40°C ~ 70°C | Silver Nickel (AgNi) | CCC, CE, CSA, cURus, EAC, ENEC, RINA, UKCA, VDE | General Purpose | - | - |
|
|
55.32.9.125.0094IND. PLUG-IN RELAY, DPDT 10A, 12 |
0 |
|
برگه مشخصات |
55 | Bulk | Active | Socketable | 125VDC | DPDT (2 Form C) | 10 A | 400VAC - Max | 4000VA | 7.2 mA | Non Latching | Diode, Lighted Indicator, Test Button | Plug In | - | - | 100 VDC | 25 VDC | 10 ms | 5 ms | -40°C ~ 85°C | Silver Nickel (AgNi) | CCC, CE, CSA, cURus, EAC, ENEC, RINA, UKCA, VDE | General Purpose | - | - |
|
|
RH2B-UAC48VRELAY PLUG-IN DPDT 10A 48VAC |
0 |
|
برگه مشخصات |
RH | Bulk | Active | Socketable | 48VAC | DPDT (2 Form C) | 10 A | 240VAC, 30VDC - Max | 2400VA, 300W | - | Non Latching | - | Plug In, Quick Connect - 0.187" (4.7mm) | - | - | 38.4 VAC | 14.4 VAC | 20 ms | 20 ms | -25°C ~ 70°C | Silver Cadmium Oxide (AgCdO) | CE, CSA, cURus, TUV | General Purpose | - | - |
|
|
RH2B-UAC50VRELAY PLUG-IN DPDT 10A 50VAC |
0 |
|
برگه مشخصات |
RH | Bulk | Active | Socketable | 50VAC | DPDT (2 Form C) | 10 A | 240VAC, 30VDC - Max | 2400VA, 300W | - | Non Latching | - | Plug In, Quick Connect - 0.187" (4.7mm) | - | - | 40 VAC | 15 VAC | 20 ms | 20 ms | -25°C ~ 70°C | Silver Cadmium Oxide (AgCdO) | CE, CSA, cURus, TUV | General Purpose | - | - |
