پد، ورق
| عکس | شماره قطعه تولیدکننده | موجودی | تعداد | برگه مشخصات | سری | بسته بندی | وضعیت محصول | استفاده | تایپ کنید | شکل | طرح کلی | ضخامت | مواد | چسب | پشتیبان، حامل | رنگ | مقاومت حرارتی | هدایت حرارتی |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
VFSFAR-050050010-00THERMAL FOIL |
0 |
|
برگه مشخصات |
- | Bulk | Active | Heat Transfer Low Thermal Resistance | Conductive Pad, Sheet | Square | 50.00mm x 50.00mm | 0.0394" (1.000mm) | Silicone | Tacky - Both Sides | Fiberglass | Gray, White | - | 6.0W/m-K |
|
|
QB0603A25ESTTHERMAL CONDUCTOR Q-BRIDGE |
0 |
|
برگه مشخصات |
Q-Bridge | Tape & Reel (TR) | Active | Heat Transfer | Thermal Bridge Jumper | Rectangular | 1.52mm x 0.76mm | 0.0025" (0.064mm) | Aluminum Nitride | - | - | - | 13°C/W, 20°C/W | 50W/m-K, 76W/m-K |
|
8810-RECTIFIERTHERM PAD W/ADH WHT |
0 |
|
برگه مشخصات |
8810 | Bag | Obsolete | Rectifier | Transfer Tape | Rectangular | - | 0.0098" (0.250mm) | Acrylic | Adhesive - Both Sides | Polyester | White | - | 0.6W/m-K |
|
|
VFSFAN-050050010-00THERMAL FOIL |
0 |
|
- |
- | Bulk | Active | Heat Transfer Low Thermal Resistance | Conductive Pad, Sheet | Square | 50.00mm x 50.00mm | 0.0394" (1.000mm) | Silicone | Tacky - Both Sides | Fiberglass | Gray, White | - | 6.0W/m-K |
|
|
VFSFAR-030030030-00THERMAL FOIL |
0 |
|
برگه مشخصات |
- | Bulk | Active | Heat Transfer Low Thermal Resistance | Conductive Pad, Sheet | Square | 30.00mm x 30.00mm | 0.1181" (3.000mm) | Silicone | Tacky - Both Sides | Fiberglass | Gray, White | - | 6.0W/m-K |
|
188961F00000THERM PAD 19.05MMX10.41MM GRAY |
0 |
|
- |
In-Sil-8 | Bulk | Active | TO-218, TO-220, TO-247 | Pad, Sheet | Rectangular | 19.05mm x 10.41mm | 0.0090" (0.229mm) | Silicone | - | - | Gray | 1.50°C/W, 1.16°C/W | - |
|
|
QB0402A20WYCTHERMAL CONDUCTOR Q-BRIDGE |
0 |
|
برگه مشخصات |
Q-Bridge | Tray | Active | Heat Transfer | Thermal Bridge Jumper | Rectangular | 1.02mm x 0.51mm | 0.0020" (0.051mm) | Aluminum Nitride | - | - | - | 16°C/W, 25°C/W | 40W/m-K, 61W/m-K |
|
|
53-77-11THERM PAD 26.16X13.21MM GRY/GRN |
0 |
|
- |
Thermalsil™III | Bulk | Active | TO-220 | Pad, Sheet | Rectangular | 26.16mm x 13.21mm | 0.0060" (0.152mm) | Silicone Rubber | - | - | Gray, Green | - | 0.9W/m-K |
|
|
QB0505A25WYTTHERMAL CONDUCTOR Q-BRIDGE |
0 |
|
برگه مشخصات |
Q-Bridge | Tape & Reel (TR) | Active | Heat Transfer | Thermal Bridge Jumper | Square | 1.27mm x 1.27mm | 0.0025" (0.064mm) | Aluminum Nitride | - | - | - | 7°C/W, 10°C/W | 100W/m-K, 153W/m-K |
|
|
4720AHARD ANODIZED ALUMINUM INSULATOR |
0 |
|
- |
- | Bulk | Active | - | - | - | - | 0.0040" (0.102mm) | Aluminum | - | - | - | - | - |
|
TG-A6050-20-10-0.5THERM PAD 20MMX10MM RED |
0 |
|
برگه مشخصات |
TG6050 | Box | Obsolete | - | Conductive Pad, Sheet | Rectangular | 20.00mm x 10.00mm | 0.0197" (0.500mm) | Silicone Elastomer | Tacky - Both Sides | - | Red | - | 6.0W/m-K |
|
|
TI900-105-27-0.12-0THERM PAD 105MMX27MM W/ADH WHT |
0 |
|
برگه مشخصات |
Ti900 | Box | Active | - | Conductive Insulator Pad | Rectangular | 105.00mm x 27.00mm | 0.0050" (0.127mm) | Silicone | Adhesive - One Side | Viscose | White | - | 1.8W/m-K |
|
|
VFSHAN-050050005-00THERMAL FOIL |
0 |
|
برگه مشخصات |
- | Bulk | Active | Heat Transfer Low Thermal Resistance | Conductive Pad, Sheet | Square | 50.00mm x 50.00mm | 0.0197" (0.500mm) | Silicone | Tacky - Both Sides | Fiberglass | Gray, White | - | 8.0W/m-K |
|
|
A13781-0001 EC 12-001PAD,GTR,.006X0.380X01.500,A1M1 |
0 |
|
- |
- | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - |
|
|
VFSFAN-030030030-00THERMAL FOIL |
0 |
|
- |
- | Bulk | Active | Heat Transfer Low Thermal Resistance | Conductive Pad, Sheet | Square | 30.00mm x 30.00mm | 0.1181" (3.000mm) | Silicone | Tacky - Both Sides | Fiberglass | Gray, White | - | 6.0W/m-K |
|
|
VFSBBN-100100010-00THERMAL FOIL |
0 |
|
برگه مشخصات |
- | Bulk | Active | Heat Transfer Low Thermal Resistance | Conductive Pad, Sheet | Square | 100.00mm x 100.00mm | 0.0394" (1.000mm) | Silicone | Tacky - Both Sides | Fiberglass | Gray, White | - | 1.5W/m-K |
|
TG-AL373-24.2-24.2-1.0-0THERM PAD 24.2MMX24.2MM YLW |
0 |
|
برگه مشخصات |
L37-3 | Box | Active | - | Conductive Pad, Sheet | Square | 24.20mm x 24.20mm | 0.0394" (1.000mm) | Silicone Elastomer | - | Fiberglass | Yellow | - | 1.7W/m-K |
|
TG-A6050-24-21.01-0.5THERM PAD 24MMX21.01MM RED |
0 |
|
برگه مشخصات |
TG6050 | Box | Obsolete | - | Conductive Pad, Sheet | Rectangular | 24.00mm x 21.01mm | 0.0197" (0.500mm) | Silicone Elastomer | Tacky - Both Sides | - | Red | - | 6.0W/m-K |
|
|
2190914BERGQUIST GAP PAD TGP 1000VOUS |
0 |
|
برگه مشخصات |
- | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - |
|
|
189654F00000GTHERM PAD W/ADH GRAY |
0 |
|
- |
In-Sil-8 | Bulk | Active | TO-218, TO-220, TO-247 | Pad, Sheet | - | - | - | Silicone | Adhesive - One Side | - | Gray | - | - |
