COB های LED، موتورها، ماژول ها، نوارها
| عکس | شماره قطعه تولیدکننده | موجودی | تعداد | برگه مشخصات | سری | بسته بندی | وضعیت محصول | تایپ کنید | رنگ | CCT (K) | طول موج | پیکربندی | شار نور @ جریان / دما | فعلی - تست | دما - تست | ولتاژ - جلو (Vf) (نوع) | Lumens/Watt @ Current - تست | فعلی - حداکثر | CRI (شاخص رندر رنگ) | زاویه دید | ویژگی ها | اندازه / ابعاد | ارتفاع | سطح ساطع نور (LES) | نوع لنز |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CHM-6-65-80-27-XH00-F2-3LED COB CHM6 CL WH SQUARE 6500K |
0 |
|
برگه مشخصات |
CHM-6 | Tray | Obsolete | Chip On Board (COB) | White, Cool | 6500K 3-Step MacAdam Ellipse | - | Square | 1320lm (Typ) | 480mA | 85°C | 27V | 102 lm/W | 720mA | 80 | 120° | - | 13.50mm L x 13.50mm W | 1.37mm | 6.30mm Dia | Flat |
|
|
CHM-6-65-80-27-XH00-F2-5LED COB CHM6 CL WH SQUARE 6500K |
0 |
|
برگه مشخصات |
CHM-6 | Tray | Obsolete | Chip On Board (COB) | White, Cool | 6500K 5-Step MacAdam Ellipse | - | Square | 1320lm (Typ) | 480mA | 85°C | 27V | 102 lm/W | 720mA | 80 | 120° | - | 13.50mm L x 13.50mm W | 1.37mm | 6.30mm Dia | Flat |
|
|
CHM-9-27-80-36-AA00-F2-3LED COB CHM9 WM WH SQUARE 2700K |
0 |
|
برگه مشخصات |
CHM-9 | Tray | Obsolete | Chip On Board (COB) | White, Warm | 2700K 3-Step MacAdam Ellipse | - | Square | 1305lm (Typ) | 360mA | 85°C | 35V | 104 lm/W | 545mA | 80 | 120° | - | 15.00mm L x 15.00mm W | 1.37mm | 9.00mm Dia | Flat |
|
CHM-9-30-80-36-XH02-F2-3LED COB SENSUS WM WHT SQ 3000K |
0 |
|
- |
Sensus™ | Tray | Obsolete | Chip On Board (COB) | White, Warm | 3000K 3-Step MacAdam Ellipse | - | Square | 2460lm (Typ) | 720mA | 85°C | 36V | 95 lm/W | 1.05A | 80 | 120° | - | 19.00mm L x 19.00mm W | 1.37mm | 9.00mm Dia | Flat |
|
|
CHM-9-30-90-36-XH02-F2-3LED COB SENSUS WM WHT SQ 3000K |
0 |
|
- |
Sensus™ | Tray | Obsolete | Chip On Board (COB) | White, Warm | 3000K 3-Step MacAdam Ellipse | - | Square | 1990lm (Typ) | 720mA | 85°C | 36V | 77 lm/W | 1.05A | 90 | 120° | - | 19.00mm L x 19.00mm W | 1.37mm | 9.00mm Dia | Flat |
|
|
CHM-14-35-80-36-XH02-F2-3LED COB SENSUS WARM WHT SQ 3500K |
0 |
|
- |
Sensus™ | Tray | Obsolete | Chip On Board (COB) | White, Warm | 3500K 3-Step MacAdam Ellipse | - | Square | 6480lm (Typ) | 1.68A | 25°C | 36V | 107 lm/W | 2.52A | 80 | 120° | - | 17.50mm L x 17.50mm W | 1.37mm | 13.50mm Dia | Flat |
|
|
CHM-14-35-90-36-XH02-F2-3LED COB SENSUS WARM WHT SQ 3500K |
0 |
|
- |
Sensus™ | Tray | Obsolete | Chip On Board (COB) | White, Warm | 3500K 3-Step MacAdam Ellipse | - | Square | 5185lm (Typ) | 1.68A | 25°C | 36V | 107 lm/W | 2.52A | 90 | 120° | - | 17.50mm L x 17.50mm W | 1.37mm | 13.50mm Dia | Flat |
|
|
CHM-9-35-80-36-XH02-F2-3LED COB SENSUS WARM WHT SQ 3500K |
0 |
|
- |
Sensus™ | Tray | Obsolete | Chip On Board (COB) | White, Warm | 3500K 3-Step MacAdam Ellipse | - | Square | 3430lm (Typ) | 720mA | 85°C | 36V | 132 lm/W | 1.05A | 80 | 120° | - | 19.00mm L x 19.00mm W | 1.37mm | 9.00mm Dia | Flat |
|
|
CHM-9-35-90-36-XH02-F2-3LED COB SENSUS WARM WHT SQ 3500K |
0 |
|
- |
Sensus™ | Tray | Obsolete | Chip On Board (COB) | White, Warm | 3500K 3-Step MacAdam Ellipse | - | Square | 3015lm (Typ) | 720mA | 25°C | 36V | 116 lm/W | 1.05A | 90 | 120° | - | 19.00mm L x 19.00mm W | 1.37mm | 9.00mm Dia | Flat |
|
|
LE UW D1W1 01-7L5M-IM-T10-HELED MOD OSRAM OSTAR WHITE |
0 |
|
- |
OSRAM OSTAR | Bulk | Obsolete | LED Module | White | - | - | - | 171lm (Typ) | 700mA | 25°C | 3.7V | 66 lm/W | 1A | - | 120° | - | - | - | - | - |
|
|
LE UW U1A5 05-5Q8Q-EBXD68LED MOD OSRAM OSTAR WHITE |
0 |
|
برگه مشخصات |
OSRAM OSTAR | Bulk | Obsolete | LED Module | White | - | - | - | 915lm (Typ) | 500mA | 25°C | 3.05V | - | 1.2A | - | 120° | - | 20.00mm L x 20.00mm W | 2.41mm | - | Flat |
|
|
LE UW U1A5 05-5Q7Q-EBXD68-T10-HELED MOD OSRAM OSTAR WHITE |
0 |
|
برگه مشخصات |
OSRAM OSTAR | Bulk | Obsolete | LED Module | White | - | - | - | 855lm (Typ) | 500mA | 25°C | 3.05V | - | 1.2A | - | 120° | - | 20.00mm L x 20.00mm W | 2.41mm | - | Flat |
|
|
LE UW U1A5 05-5Q7Q-EBXD68-L-ALLED MOD OSRAM OSTAR WHITE |
0 |
|
برگه مشخصات |
OSRAM OSTAR | Bulk | Obsolete | LED Module | White | - | - | - | 855lm (Typ) | 500mA | 25°C | 3.05V | - | 1.2A | - | 120° | - | 20.00mm L x 20.00mm W | 2.41mm | - | Flat |
|
|
LE UW U1A5 05-5Q6QEBXD68-T10-HELED MOD OSRAM OSTAR WHITE |
0 |
|
برگه مشخصات |
OSRAM OSTAR | Bulk | Obsolete | LED Module | White | - | - | - | - | 500mA | 25°C | 3.05V | - | 1.2A | - | 120° | - | 20.00mm L x 20.00mm W | 2.41mm | - | Flat |
|
2702221LED ENG CL WHT LNR STRIP 5000K |
0 |
|
برگه مشخصات |
- | - | Obsolete | LED Engine | White, Cool | 5000K | - | Linear Light Strip, Plug and Play | 140lm (Typ) | - | - | 24V | - | - | 75 | - | - | 250.00mm L x 23.00mm W | 38.00mm | - | - |
|
2702222LED ENG CL WHT LNR STRIP 5000K |
0 |
|
برگه مشخصات |
- | - | Obsolete | LED Engine | White, Cool | 5000K | - | Linear Light Strip, Plug and Play | 340lm (Typ) | - | - | 24V | - | - | 75 | - | - | 375.00mm L x 23.00mm W | 38.00mm | - | - |
|
2702223LED ENG COOL WHT RECT 5000K |
0 |
|
برگه مشخصات |
- | - | Obsolete | LED Engine | White, Cool | 5000K | - | Rectangle | 560lm (Typ) | - | - | 24V | - | - | 75 | - | - | - | 38.00mm | - | - |
|
2702224LED ENG NEUT WHT RECT 4000K |
0 |
|
برگه مشخصات |
- | - | Obsolete | LED Engine | White, Neutral | 4000K | - | Rectangle | 685lm (Typ) | - | - | - | - | - | 85 | - | - | 265.00mm L x 91.00mm W | 44.00mm | - | - |
|
|
LE B P2W-FZGY-W4-0-F00-T01LED MOD OSRAM OSTAR BLUE RECT |
0 |
|
- |
OSRAM OSTAR | Tray | Obsolete | LED Module | Blue | - | 459nm (452nm ~ 465nm) | Rectangle | - | 24A | 25°C | 3.55V | - | - | - | 120° | - | 27.00mm L x 15.50mm W | 2.10mm | - | Flat |
|
SI-B8P09A280WWLED MOD LT-R286A WHT RECT 6500K |
0 |
|
- |
LT-R286A | Tray | Obsolete | LED Module | White, Cool | 6500K 4-Step MacAdam Ellipse | - | Rectangle | 1501lm (1350lm ~ 1650lm) | 290mA | 50°C | 32.3V | 160 lm/W | 540mA | 80 | 115° | With Connector | 280.00mm L x 55.00mm W | 5.80mm | - | Flat |
